Product Overview
Made from USA 3mm carbon. Mayhem has some great adjustment features that nobody else has. Features: Infinite sliding battery adj. Adjustable stand up battery mount, Lwt Aluminum 25 deg kick up w/ droop screw provisions, 3d Bulkhead with raised steering arm location for improved bump steer adjustment, Standup/ layover front shock tower design for Improved handling and driver feel, 1/2 offset chassis plate for ultimate grip and steering, slotted cage holes for quicker removal of cage, more roll center adjustments. Plus many more cool features!! WE CAN PRINT MANY COLORS FOR THE 2 3D PARTS. ADD TO NOTES IF YOU WOULD LIKE A DIFFERENT COLOR. BLACK IS STANDARD.
THIS IS A CONVERSION FOR B6 THRU B6.4 BUGGYS.
SPECIAL INSTRUCTIONS
1: RIGHT FRONT STEERING TURNBUCKLE MUST BE 32MM (MUST DO THIS FOR CLEARANCE FROM RACK TO CAGE)
2: STEERING 3/4 STUD MUST BE SCREWED ALL THE WAY INTO THE EYE FOR SERVO ROD. 10 mm threads showing.
3: SLIGHT CLEARANCING OF CAGE WHERE STEERING RACK HITS IT PREFERED BUT NOT A MUST.
4. SLIGHT CLEARANCING OF STEERING RACK WHERE IT HITS CAGE.
5: ADJUST LEFT SIDE STEERING TURNBUCKLE TO GET TOE TO 1 DEG OUT
KIT INCLUDES
CARBON PARTS
Chassis plate
front and rear shock towers
rear bumper plate
3MM REAR LOWERING PLATE BUMPER EXTRAS
PPP-0113 stand up o ring battery mount,
PPP-0530 ALUMINUM 25 deg kick up,
3 D PARTS
PPP-0905-25 Bulkhead,
PPP-0906 3d rear BUMPER MOUNT SPACER
PPP-0937 SERVO MOUNT
HARDWARE
3/4 STUD FOR STEERING
4x 30mm button head bolts for rear shock tower/ TOWER MOUNT.
4X 20MM Button head bolts for front kick up going into bulkhead.
4X 16MM CS FOR MOUNTING SERVO MOUNT TO CHASSIS PARTS
NEEDED TO COMLETE GFRP CAGE KIT/ BODY You will need B6-B6.4 donar kit or ASC90033 builders kit, PPP213 MIRAGE BODY KIT Pictures are of built car only parts listed are inlcuded. RECCOMMENDED PARTS CW1824 WHITE SPRINGS (YELLOW ON RF, LF, LR. WHITE ON RR) CW1825X2 YELLOW 4# SPRINGS CW3226 TAIL TANK POST JCO2565-2 ALUMINUM STEERING JCO2582-2 ALUMINUM STEERING ASC91658 ALUMINUM BULKHEAD ASC91800 SLIPPER ELIMINATOR ASC91777 REAR ARMS PPP104 CARBON FIBER MOTOR PLATE OPTION 1 PPP950 3D FAN MOUNT PPP911 BLADDER SPACERS PPP911B BLADDERS
